CH- AC2000 series frame type air cooled air conditioner（3KW~12KW）
AC2000 series frame type air-cooled air conditioner, placed close to the heat source in the cabinet, can accurately handle the high apparent heat generated by the server in the cabinet, effectively prevent local hot spots.
The rack air conditioner is installed in the cabinet. The cabinet closes the hot and cold channels, and combines with a high efficiency DC frequency conversion compressor to achieve high efficiency cooling close to the heat source. It meets the cooling requirements of small and medium-sized enterprises in the full cooling capacity segment and 5GBBU cabinets.
Rack-mounted air conditioners provide all the functions of conventional air conditioners in equipment rooms, including cooling, heating, humidification, dehumidification, air filtration, environmental control and monitoring, and data communication. They are energy-saving, reliable, and adaptive.
Product
consult.png)
-
Efficient and reliableEfficient cooling: Optimal system matching and efficient cooling coil design ensure efficient heat transfer.
High-efficiency electronic expansion valve: ultra-precise control technology, perfectly matching inverter compressor and EC fan, more efficient and energy-saving. -
Green energy savingNew generation of EC fan: material improvement and performance greatly improved, real-time distribution of air volume on demand, high efficiency and energy saving, high intelligence, long life, low vibration, low noise.
Precision control: temperature control accuracy can reach ± 0.3℃, humidity control accuracy can reach ± 3% to create a more stable operating environment for equipment in the equipment room.
Wide power supply: can meet 220V± 15%2N ~ 50Hz± 2Hz power supply. -
Intelligent controlIntelligent monitoring: The system can be monitored and parameter set through the terminal device, which can achieve good human-computer interaction.
- Application scenario
.jpg)
- Small or Distributed IT Cabinets
.jpg)
- Edge Computing Integrated Cabinet
.jpg)
- Solution Integrated Cabinet
.jpg)
- Computing deployment scenarios such as enterprise Micro and small data centers
- Technical specification
| Model | AC2000-3 Series | AC2000-5 Series | AC2000-7 Series | AC2000-12 Series |
| Cooling capacity (kw) | 3.5 | 5 | 7.5 | 12.5 |
| Cooling capacity (kw) | 3.5 | 5 | 7.5 | 12.5 |
| Air volume (m³ /h) | 800 | 1100 | 1650 | 2200 |
| Air supply mode | Horizontal air supply | |||
| Function | Optional constant temperature and humidity function | |||
| PTC Electric heating (kw) | 1 | 1 | 1 | 2 |
| Humidifier (kg/h) | 1 | 1 | 1.5 | 3 |
| Refrigerant | R410A | |||
| Indoor unit power supply (V/PH/Hz) | 220/1/50 | |||
| Indoor unit size: Width * Depth * Height (mm) | 443*715*218 | 443*715*218 | 443*715*351 | 443*715*440 |
| Indoor unit weight (kg) | 27 | 28 | 36 | 42 |
| Outdoor unit power supply (V/PH/Hz) | 220/1/50 | |||
| Outdoor unit Dimensions (mm) | 794*310*537 | 794*310*537 | 1045*431*760 | 1045*431*1375 |
| Outdoor unit weight (kg) | 30 | 34 | 60 | 85 |
| Protection Class | IPX4 | |||
